Description : Sliding binocular view head Strain free objectives Eyepiece with scale of cross hair ( optimum focus and accurate measurements ) Eyepiece graticule ( measure object ) Central adjustable backward quadruple noise piece Revolving round stage ( 1° increment ) Centrally adjustable bertrand lens ( sliding in/out of optical path ) Digital camera for image analysis ( optional )

Specifications :

Viewing head	Binocular
Eyepiece	WF10X / 18
Optical compensator	λ Slip (First class red) 1/ 4λ Slip Quartz wedge
Achromatic objective	4X 10X
Plan achromatic objective	25X 40X 63X
Stage diameter	160 mm
Nosepiece	Backward quadruple
Analyzer gradation	0° ⁓ 90°
Illumination	12 V / 50 W
Dimensions	490 × 330 × 400 mm
Weight	12 kg

Features : Reflective polarizing microscope MRPM-1A bench-top unit integrated with dual polarizing filters. Halogen lamp provide bright illumination. Optimized stress and strain free objectives are used with polarized light providing bright crisp images. Coaxial coarse and fine adjustment focus knob with tension adjustment aids in mobility of the objective lenses. Optional digital camera can be incorporated for image analysis.

Applications: Used widely for geology, minerals, metallurgy, laboratories and other sectors. Used in chemical fiber industries, semiconductor and pharmaceutical inspection industries.

Optional Accessories: Accessory No Accessory Accessory Specification RPMA1 Photo attachment Nikon(Connect to Nikon digital single lens reflex) RPMA2 Photo attachment Canon(Connect to Canon digital single lens reflex) RPMA3 Video attachment C Mount 1X RPMA4 Objective Lamp house adjustment objective RPMA5 Accessory Specimen presser

Standard Accessories: Accessory No Accessory Accessory Specification 1. Viewing head Binocular 2. Eyepiece WF10X / 18with scale of cross hair 3. Eyepiece WF10X / 18 with graticule 4. Eyepiece WF10X / 18 5. Strain free objective Achromatic objective 4X 6. Strain free objective Achromatic objective 10X 7. Strain free objective Plan achromatic objective 25X 8. Strain free objective Plan achromatic objective 40X 9. Strain free objective Plan achromatic objective 63X 10. Nosepiece Quadruple nosepiece 11. Accessory Mechanical stage ( 30 mm ×40 mm ) 12. Accessory Micrometer
